Belle FC3600E PCX 12/36 Honda Petrol Plate Compactor Efficient Soil Compaction for Construction Jobs

Heavyweight. professional compaction plates with low Hand Arm Vibration and very high performance compaction. Designed with a shorter baseplate to offer improved compaction. manoeuvrability and finish.

Features:

Foldable mounted guide handle offers superior manoeuvrability and can be lowered to operate under obstacles and close to form work.
Reinforced centrifugal clutch ensures longer belt life. and simplified belt adjustment.
Lifting points and front lift cage offer easier loading and unloading for operator convenience.
Angled holes on spray bar allow complete water coverage over the full width preventing any asphalt pick-up on plate bottom.
The spraybar is fully protected from damage. easily positioned with integral paving pad clamp points.
Life lubricated vibration bearings.
Optional:- compact wheelkit easily fitted and removed. large capacity water tank is built into the protective frame. block paving pads.

Product Specification:

Part no: FC3600E
Barcode: 5031403409386
Model: PCX 12/36
Engine Model: Honda GX120 Petrol
Engine Power: 3.3hp / 2.4 kW
Plate Size WxL: 360 x 606 mm
Static Pressure: 586 kg/m2
Centrifugal Force : 12.25 kN
Travel Speed: 20 m/min
Vibration: 4.74 m/sec2
Weight: 8.10 kg

**images for illustrative purposes only please refer to description and specification for full details of product**
